Next you will need to determine if your golf cart has a Series Motor or a Regen Motor. This is fairly straight forward. You will have several tell tail signs that will help you determine the type of electric golf cart motor and system that is in your golf cart.
How To Determine The Difference Between Series or Regen Electric Golf Cart Motors
Customers ask me all the time for a faster motor or want to make their golf cart faster. I ask what kind of cart do you have? What is the set up Series or Regen? Same answer – I Don’t Know??? How can I tell they ask, so here you go a few basic ways to find out quickly.
Regen Carts – “Golf Carts with regenerative braking systems.”
- If you have a Run / Tow or Run / Maint. switch under the seat it is a Regen motor. See Picture below…
- If your golf cart motor has wires coming out the end and has a speed sensor it is a Regen Motor.
- If your golf cart has a toggle switch for the Forward / Reverse Selector you have a regen cart
- Lastly if you are under the golf cart and you see two different size threaded anchor bolts 2x @1/4″-20 and 2x @5/16″-20 it is a regen motor.
- If you look under the seat and you Do NOT have a Run / Tow or Run / Maint. Switch it is a Series Motor System.
- If you do not have wires coming out the end of the motor or speed sensor you have plain motor or Series motor system.
- If your golf cart has a handle and throw lever for the Forward / Reverse Selector you have a Series Motor
- Lastly if you are under the golf cart and you see two different sets of threaded anchor bolts but all are the same size 5/16″-20 it is a series motor.
Lets start off with the Why… Your Electric Golf Carts system is designed to store energy in the battery bank and distribute that energy to your golf carts electric motor to create motive power to carry you down the road, trail or across the green. The only way you can get that power to the golf cart motor is via the conductors or cables connecting all your golf cart batteries.
If you notice your original golf cart cables are cracked or showing exposed wire during your usual inspections they should be replaced immediately. If your connectors are showing signs of corrosion they should be cleaned and protected immediately with a product like BatteryPete’s Corrosion Block or Preventative. This is because where ever there is resistance it will generate heat but also severely limit the performance of your golf carts electric system. ( Picture a beautiful natural fresh water mountain stream. Come Spring time it is flowing well as the snow in the mountains above starts to melt. (This would be your battery cable system in good form.) Then Mr. Beaver decides to build a nice little damn and block the flow of your stream, this is what you get with the electricity trying to pass thru a electrical system with corrosion on connections, frayed wires, or loose connections. ( Even more so apparent on high performance systems when you would upgrade the motor/controller in your golf cart to provide more speed or torque ) In this case just bigger diameter wires are needed to handle the additional flow of voltage and amperage.
So when the time comes to replace those battery cables you will want to do one specific thing before you dig into your afternoon project. Get your smart phone out and snap a few pictures. This way you have a frame of reference and can go back to if need be to make sure you wire up the battery bank correctly. Usually after removal of all cables and / or before we will clean the area and battery terminals. Depending on how bad they are will determine the course of action. Usually we will hit them with a small wire brush and then spray off with a hose or pressure washer. Water dilutes battery acid and a good time to clean out the battery hold on your golf cart to curb corrosion damage. Also nicer to work in a clean area…
After that we will spray a corrosion preventative on all the battery terminals, let sit for a few minutes and proceed to attach new battery cables to all the batteries in question. Being sure to attach with a SS nut and SS Lock Washer on every connection to make sure they do not corrode or come loose over time. ” Remember – resistance generates heat!” A loose wire under a load ( You holding the gas pedal to the floor for a few minutes) will cause a battery connector to melt straight through to the plastic battery case… ” Which will require a battery replacement or repair ” Both can be expensive! Preventive maintenance is always the best approach to vehicle ownership. Once you have connected all the batteries again with the new battery cables, you should go back through each connection and double check it is snug ( A Good quarter turn with a ratchet on each will ensure success ) Then last but not least another round of spraying some Anti-Corrosive on the battery terminals to prevent corrosion build up.
